| Place of Origin: | China |
| Brand Name: | ZEMO |
| Certification: | CE, ISO |
| Model Number: | SMD-NS610A |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | AL boxes + carton |
| Delivery Time: | 3-5 days after payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Product Name: | E Hand Held Plastic Extruder For Sheet Geomembrane Pipe | Voltage: | 220V 50/60HZ |
|---|---|---|---|
| Condition: | New | Extruding Motor Power: | 1300W |
| Hot Air Power: | 1600W | Welding Rod Heating Power: | 800W |
| Air Temp.: | 20-620 ℃ Adjustable | Extruding Volume: | 2.0KG/h |
| Welding Rod Diameter: | 3.0-5.0mm | N.W: | 6.5KG |
| Driving Motor: | Metabo | Thickness Welded: | 8-40MM |
| High Light: | 800W Hand Held Plastic Extruder,Hand Held Plastic Extruder 20mm,Pipe hand held plastic extrusion welder |
||
Extrusion Welding Machine For Welding Geomembrane is a new type of hot air welder which imported foreign advanced technology, well-developed,.It has reached or exceeded the same type products of oversea, filling the domestic blank. The major components (hot air gun and drive motor) are made of imported brand-name accessories, stable performance, long service life .
| Product Name | Hand Held Plastic Extruder For Sheet Geomembrane Pipe |
|
Model
|
SMD-NS610A
|
|
Input voltage
|
220V
|
|
Frequency
|
50/60Hz
|
|
Extruding power
|
1300W
|
|
Hot air power
|
1600W
|
|
Welding rod heater power
|
800W
|
|
Air Temperature
|
20-620℃
|
|
Extruding temperature
|
50-380℃
|
|
Extruding volume
|
2.0 - 2.5Kg/h
|
|
Welding rod diameter
|
3 - 5 mm
|
|
Weight
|
6.9 Kg
|
|
Driving motor
|
Metabo |
|
Materials thickness
|
1 - 20mm
|
Tips:
a. Preheating 3-5 mins and make previous welding flux soften, then using tools to pick out the softened flux before start work.
b. This Hand Extruder is welded with PE/PP/HDPE welding rod Φ3.0-4.5mm, the welding speed is 1.8-3.6Kg/h.
c. Any customized demands, you can ask us directly. We have professional technicians team.
